1MP Wifi Smoke Detector Spy Camera Instructions

Table of Contents

1 1MP Wifi Smoke Detector Spy Camera Instructions

Smoke Detector Spy Camera 1MP Wifi

The 1MP Wifi Spy Camera Smoke Detector is a compact and discreet device that allows you to capture high-quality images and videos easily and efficiently. Equipped with 5.0MP CMOS sensor, this camera guarantees accurate color reproduction and excellent image quality. Supports microSD up to 64GB and includes plugs and screws for fixing to the wall or ceiling.

Technical characteristics

Offer great image quality, with resolution of 1980*1080P. Every detail will be captured with precision and clarity.

Capture images or videos of quality with the 5.0MP CMOS image sensor with 75º lens angle and automatic night vision.

The files They are stored on a microSD (not included). Supports microSD from 2GB to 64GB (minimum Class 10).

The function of Wi-Fi streaming allows you to connect to the camera via LookCam app for IOS/Android and view images in real time.

incluye una built-in rechargeable battery. This battery can be 100% charged in 2-3 hours and offers Up to 3 hours of use.

Content

Smoke Detector Spy Camera 1MP Wifi

USB Charging and Transfer Cable

2 x Plugs and Screws for Fixing

Manual

Instructions

Step 1 - Opening and Inserting microSD

Smoke detector hides a compartment for the MicroSD slot.

FOR open the rear compartment it is due to Turn the rear cover counterclockwise.

When inserting the microSD into the slot we must push the microSD until you hear a click, and push again to extract it. It is recommended to format the card to FAT 32 format and use a card with a Class 10 transfer speed. The minimum size allowed is 2 GB and the maximum 64 GB.

Step 2 - Load

The battery is shipped with a low charge. It must of charge with a USB charger.

The smoke detector emits a Red light while charging that turns off when charging is 100%:

El charging time is about 2-3 hours when connected to a 1 amp charger at 5 Volts (Maximum 5V 1.0A, using more amperage will reduce battery life).

Step 3 - Power On/Off

Turn on the smoke detector by moving the switch to "WE".

After a few seconds The red LED will turn on steadily and the blue LED will flash.

FOR delete, move the switch to the OFF position.

Step 4 - Wifi Remote Viewing

Step 4.1 - Application Download

Download the LookCam app on your mobile by pressing the Android or App Store (iPhone) icon depending on the model of your device.

Step 4.2 - Wifi connection

On ignition wait at least 1 minute for wifi to be activated. When Wi-Fi is activated, a blue and red light will flash. Next, access the mobile's Wi-Fi settings and connect to the G wifi network… If a notice appears when connecting indicating that this Wi-Fi network does not have internet and showing the option to maintain the connection or disconnect it, we must maintain the connection.

Step 4.3 - Viewing and Configuration

The application will recognize the Wi-Fi of the device to which we are connected and we will be able to view the live image. This allows you to view it in local mode connected to the camera's Wi-Fi, but the configuration for remote viewing has not yet been completed.

Pressing in gear icon On the main screen we can modify the camera parameters and connect the camera to a Wi-Fi network:

Connect to the camera's Wi-Fi network.
Grant all permissions in the app.
Click OK in the message that appears when you open the app or on the gear wheel on the camera that will have detected the app automatically.
If you have clicked on the gear wheel, click on Wifi setting.
Select the Wi-Fi network to which the camera will connect. The Wi-Fi network must be 2.4GHz type.
Enter the password for the Wi-Fi network.
Confirm the configuration.

When the connection is successful the blue led will stop flashing and you will return to the main screen of the app. We can view the camera from anywhere with internet.

Step 4.4 - Display Settings

Through the application we can adjust some parameters visualization such as night vision or turning off the detector LEDs.

The detector includes a microphone which can be activated by clicking on the speaker icon in the lower left corner and increasing the volume.

Step 4.5 - Share Access

Open the application and click on the icon in the upper right corner +. Next, click on “Add new online Camera”.

From the mobile used to configure the detector Click on the gear icon to display the Camera ID.

IEnter the ID and default password: 123456 or the password we have established.

Step 5 - Reset

If the product is failing or we want to restore factory settings, while it is on, Press the reset button located to the right of the microSD slot until it clicks and hold for at least 5 seconds. Then wait 1 minute for the reset to complete.

After factory resetting the device, you must delete the camera in the app by clicking on the gear wheel and «Delete device».

If you have questions, don't hesitate to contact us! 😉

Frequent Problems

1 - Does not turn on

The battery is shipped with a low charge. It must of charge with a USB charger.

The smoke detector emits a Red light while charging that turns off when charging is 100%:

El charging time is about 2-3 hours when connected to a 1 amp charger at 5 Volts (Maximum 5V 1.0A, using more amperage will reduce battery life).

2 - Does not store

Enter the microSD into a computer and check that you can read it.

La microSD it is recommended that you have FAT32 format.

Remember to use a microSD between 2 and 64GB and that the transfer speed is minimum 10 Class.

If you have questions, don't hesitate to contact us! 😉

Security and Compliance

Below is indicated important product information in relation to the security and compliance that guarantee proper and safe use of the product:

⚠ FAILURE TO FOLLOW THESE SAFETY INSTRUCTIONS MAY RESULT IN FIRE, ELECTRIC SHOCK, OR OTHER DAMAGE OR INJURY.

Product specifications:

Model name: Smoke Detector Spy Camera 1MP Wifi

Model Number:CE-27

Product identifier: 706212918430

Product battery: Integrated Lithium-Ion type with 800 mAh capacity

Operating temperature: 0 to 35ºC

Product Use: Do not expose your device or adapter to liquids. If your device or adapter gets wet, carefully unplug all cables without getting your hands wet, and wait for the device and adapter to dry completely before plugging them back in. Do not try to dry your device or adapter with an external heat source, such as a microwave oven or blow dryer. If the device or adapter is damaged, stop using it immediately. Use only the supplied accessories to power your device. To avoid the risk of electric shock, do not touch the device or the cables connected to it during a thunderstorm. The cables and/or adapters are only designed for indoor use.

Legal notice: PingOc Now SL is not responsible for the fraudulent or erroneous use of the product due to the lack of understanding or reading of the information in the instructions and precautions. This product is not a toy and must not be used contrary to current applicable laws. If you have any questions you can contact us before using the product.

For EU customers: Hereby, PingaOculto, declares that the type of radio equipment is in accordance with Directive 2014/53/EU.

Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

FCC Compliance: This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.

This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. The device has been evaluated to meet the general RF exposure requirement. The device can be used in portable exposure conditions without restrictions.

Radio Frequency Exposure Compliance: As a health protection measure, this device complies with the limits for exposure of the general public to electromagnetic fields in accordance with council recommendation 1999/519/EC. This device can be placed on the body avoiding prolonged use of it for more than 5 hours.

How to recycle your device properly: Disposal of certain electronic devices is regulated in some areas. Make sure you comply with local regulations and laws.

Additional Safety and Compliance Information: For additional information on safety, recycling and compliance or other important issues related to your device, do not hesitate to contact us through any of the available means of contact. Means of contact with: Email contact@pingaoculto.com, Call/WhatsApp +34 644 098 320.

Limited Warranty: All official brand items PingaOculto have 2 year minimum warranty. This guarantee may be extended or reduced depending on the country where the sale takes place, as is the case by law in Spain where it is extended to 3 years as established by Decree-Law 7/2021 with respect to the Guarantee on the Sale of Goods. of consumption. We reserve the right to deny the guarantee of a product if improper or negligent use by the client is verified, similar to those reflected in: https://www.pingaoculto.es/garantias-y-devoluciones/ If you need to contact us due to a failure, you can do so by email: contact@pingaoculto.com or by Call/WhatsApp: +34 644 098 320.
